Bike Brake Cable Detached (Things You Must Know)
Adjusting bicycle brakes is a thing of art due to the precise fine-tuning it needs to work correctly.
From brake pad adjustments to cable tuning, there are multiple factors to consider while maintaining or repairing your bike’s braking system.
Detached bike brake cables should cause alarm because it means your bike’s brake failure is imminent.
In addition, different problems can separate your bike brake cables from their housing.
Bike brake cables can get detached if their adjustment knob fails or a faulty brake lever housing. A lousy brake ferrule and worn brake housing end caps could also be the culprit. Diagnosing and performing the proper repairs will stop cases of detached bike brake cables.
How to Fix a Detached Bike Brake Cable?
Fixing your bike’s detached cables with the proper material and instructions should be easy.
There are different points in your bicycle braking system where your brake cable can detach.
Here are the points your bike brake cable can get detached and things you can do to fix it.
#1. Brake Lever
Most cases of loose brake cables originate from the brake lever itself. There is a groove at the ends of brake levers that the brake cable nub slides and locks into place.
If this groove is worn or has bent out of shape, it will cause the bike brake cable to detach.
You should try sliding the brake cable into the lever to see if it would lock-in. You will have to replace your bike brake lever if it doesn’t lock in.
#2. Brake Cable
Your bike brake cable is the lifeblood of the entire braking system. Brake cables are interwoven steel wires that transfer force from your brake levers to your brake pads.
Broken or frayed cables can cause your brake cable to get detached.
Replace any detached cable that is cut or frayed beyond repair. You should remove the entire brake housing and use a plier to draw the line from inside.
The new brake cable should be installed and snipped to the required length.
#3. End Caps
End caps are the aluminum cylinders at both ends of the brake housing cable.
Broken or worn end caps will warp your brake housing and cause your brake cable to loosen and detach. You can visit sites like this for bicycle end cap replacements.
Reasons Why Bike Brake Cable Detached?
There are multiple possible reasons why your brake cable detaches and doesn’t work.
With Problems like bad brake levers and faulty noodle Joints, here are some reasons your brake cable detaches.
#1. Loose Brake Cable Nub
Bicycle brake nubs are the mallet-shaped protrusions at the end of the bike brake cables.
The brake nubs are what connects the brake lever to the brake cable. Loose or broken brake cable nubs will cause your bike cable to detach randomly.
#2. Broken Brake Levers
Brake levers generate the force that stops the bike. When your brake lever is depressed, it pulls the bike brake cables together, stopping the bicycle.
If the groove your brake nub is supposed to lock in is broken or bent, your bike brake will detach.
#3. Faulty Noodle Joint
Bicycle noodle Joints is an L-shaped elbow that connects the brake cables to the brake calipers.
If your bike noodle joint is broken or worn, your brake cable will detach whenever you apply your brakes.
#4. Worn Brake Ferrule
Brake ferrules are the small cylindrical tubes used to close the ends of bike brake cables.
Worn-out brake ferrules will cause your bike cable will twist and fray at different places. That will lead to unwanted cable slack and cause detaching.
Why Does my Brake Cable Keep on Coming out of my Brake Handle
Riding your bike on a busy street and having your brake cable suddenly Popping out can be pretty scary.
Here are some reasons why your brake cable keeps coming out of your brake handle.
#1. Frayed Brake Cable
If your bike brake cable is frayed and worn out, it won’t allow your brake cable to return correctly.
You can check for frayed wires by inspecting the ends of your brake cables, especially those after the anchor bolts.
#2. Faulty Caliper Return Spring
If your brake caliper return spring is weak or needs adjustment, your brake cable will not return correctly.
In addition, the excess brake cable in your brake lever will increase the chances of your brake cable getting dislodged.
#3. Bad Adjustment Hub
You can use the brake adjustment hub to tighten your bike braking system precisely.
However, if your adjustment hub is terrible or loose, it cannot secure your brake cable, causing it to detach easily.
#4. Incorrect Brake Clearance
Setting the proper brake clearance is crucial while adjusting your bike brakes.
Too little brake clearance will make your brake cable excessively slack, increasing the chances of your brake cable detaching.
How do you Reattach a Bike Brake Cable?
The health of your brake components determines the method to use in reattaching your bike brakes.
If your old brake levers and cables are in good condition, you can follow the first column in the table below. And follow the second if otherwise.
After identifying the place your bike brakes have loosened, you can follow these steps to reattach it successfully.
| Components In Good Health | Components In Need of Replacement |
|---|---|
| Remove the older cables and brake levers. First, loosen the anchor bolts and remove the line from the caliper. Then you spin the lever adjuster till the nub head unclips and slides out of the brake lever. You can safely now remove the brake cable and loosen the brake lever. | Remove the brake lever and loosen the Brake anchor bolts. The gear adjuster should be relaxed and the entire gear housing removed. |
| Reinstall the older cable and the brake lever. Again, it would be best if you cleaned and oiled the older components before attempting to install them. | Install the new cables and the handlebars. You must take care to ensure the new handlebars and cables match the required sizes of your bike. |
| You should install the older components back the same way they were. Avoid taking extra hoops or turns that You did not do on the original. | Ensure the new cable is the required length and cut out any excess material. |
Common Bike Brake Cable Problems and How to Solve them?
Bikes are an essential form of transportation for millions of people around the world.
Every bike owner should be able to identify and fix minor problems with their bike without calling a technician.
Here are some common faults bikes can develop and steps on how to rectify them.
- A buildup of dirt on the bike rim or pads can cause squealing. Replacing the brake pads and cleaning the braking surfaces will stop the squealing.
- Poorly tensioned brake cables cause slacking brakes. Quickly tightening and re-tensioning the bike’s anchor bolts and brake cables will remove excess slack.
Conclusion
There could be different reasons why your bike brakes get detached. It would be best to identify what is causing it to separate and take the proper steps to solve the problem.
And please, do not interchange your brake and gear cables for any reason.
